BeeVision 182 Series

Static Parcel Dimensioning System

AI-POWERED
4th GEN DIMENSIONER

First and only plug & measure dimensioner that is OIML & MID
certifed (legal-for-trade) for irregular-shaped objects.

plug & measure
at the speed of light.

Exceptionally high measuring speed combined with a minimum margin of error. Set up in less than 5 minutes and experience the incredible success of the certified sensor, whatever the characteristics of the objects to be measured

0.5 sec

SUPER FAST MEASUREMENT

0.5 cm

HIGH ACCURACY DIMENSIONING

5 mins

VERY QUICK DEPLOYMENT

highlights

BeeVision 270 Sensor
BeeVision 270 Sensor

Measure cubic or irregular shaped objects in 0.5 sec measurement time with AI-Powered sensor

Touch Screen Interface
Touch Screen and Easy UI

Calibrate and operate in seconds with high-speed responsive industrial 10" touch-screen monitor

Integrated Scale
Integrated Scale

Easy-to-use, accurate scale. Legal-for-trade weight data sent with API

and more features

Easy calibration

Simple and quick calibration process that can be completed in minutes without technical expertise.

No external PC or SW required

Standalone operation with built-in processing capabilities - no additional computer or software needed.

Barcode scanning with handheld scanner

Integrated handheld barcode scanner for easy package identification and tracking.

Compact desktop design

Space-efficient design perfect for desktop use in any warehouse or office environment.

Internal storage system

Built-in storage for measurement results and captured images with easy retrieval capabilities.

technical specs

182 182S
Area of Use Static Dimensioner Optimized for Small and Irregular Shaped Objects
Technology AI-Based 3D Image Processing
Measurable Objects Cubic or Irregular Shaped Objects
Accuracy ±0.5 cm
Integration Interface Web Service API, TCP/IP Socket, File Upload to FTP, SFTP or Samba, RS232
Product Output Width, Length, Height, Weight, Dimensional Weight, Real Volume
Maximum Power Consumption 75W
Operating Temperature 5°C - 40°C
Screen 10.1" Touch Screen
Barcode Scanning Handheld 1D/2D Barcode Scanner
Scale (Configurable) 60kg capacity, 20 gr accuracy
Measurement Area (Platform) (L x W) 60cm x 40cm (Typical) 40cm x 30cm (Typical)
Minimum Object Dimensions 5cm x 5cm x 5cm 5cm x 5cm x 2cm
Maximum Object Dimensions 80cm x 60cm x 60cm 50cm x 40cm x 40cm
Product Dimensions 82cm x 60cm x 172cm 82cm x 60cm x 123cm
Package Dimensions  Package-1: 82 x 82 x 26 cm and 20 kg
Package-2: 58 x 86 x 21 cm and 19 kg		 Package-1: 103 x 53 x 26 cm and 20 kg
Package-2: 58 x 86 x 21 cm and 19 kg

downloads

Download Brochure User Manual Software Guide

frequently asked questions

General Questions

Just drop us an email to info@beevision.ai. Please tell us also minimum and maximum object size that you would like to measure, as well as the object type and the application type: static or dynamic.

We ship worldwide!

We accept bank transfer. Our bank account number is provided with offer.

BeeVision dimensioners offer you unprecendented flexibility. You can download measurement results to your PC as an Excel file. You can browse results in Volumizer UI. You can receive results via RS232 or with web-service communication via Ethernet. You do not need to install a single SW, every setting can be changed from your browser.

BeeVision dimensioners are equipped with remote access software. We can connect to your BeeVision and guide you through it.

With BeeVision API! All you need to do is to establish a web service connection to the BeeVision Dimensioner and request data and receive response. You can do this very quickly in any programming language. Our team is happy to provide you examples if you need. BeeVision devices may behave as a client and send results automatically to your database.

The return on investment (ROI) for BeeVision 182 varies depending on your processing volume, current labor costs, and operational efficiency. Most of our customers achieve full ROI within 12 months. Transitioning from manual dimensioning to static automated dimensioning can significantly reduce labor costs, eliminate costs from operational errors, and increase overall productivity. We recommend contacting our sales team for a customized ROI analysis.
BeeVision 182 : Static Dimensioning System

BeeVision 182 is the first and only plug & measure dimensioner that is both OIML & MID certified (legal-for-trade) for irregular-shaped objects. Our AI-powered technology provides unprecedented accuracy and reliability with a minimal margin of error.

The BeeVision 182 system includes:

> BeeVision 270 Dimensioner sensor
> Compact desktop platform
> 10.1" Industrial touch screen monitor
> Integrated scale (60kg capacity, 20g accuracy)
> Handheld 1D/2D barcode scanner
> All necessary cables and mounting hardware

The BeeVision 182 is designed for extreme ease of use. Setup takes less than 5 minutes - simply place the unit on a desk or table, connect the power, and you're ready to start measuring. No external PC or software installation is required, and calibration is quick and straightforward through the touch screen interface.

The BeeVision 182 can measure both cubic (regular) and irregular-shaped objects. It works with parcels, boxes, polybags, tubes, and other shipping containers. The system can handle objects from 5cm x 5cm x 5cm up to 80cm x 60cm x 60cm, making it versatile for a wide range of applications in shipping, warehousing, and logistics operations.

Yes, the BeeVision software supports group measurement and cubic measurement operations. The Group Measurement function is designed to group sequential dimensioning tasks and send the dimensioning results to a specified network address via the Integration Menu > Server Sharing tab. Additionally, volume measurement data is saved locally on the device as an XML file (readable by Microsoft Excel), facilitating warehouse automation processes.

Yes, by enabling the "Enter results manually" option in the Measurement Settings menu of the BeeVision dimensioning device, you can register products of any size. This feature ensures accurate dimensioning and flexible data entry.

Yes, any scale supporting RS232 communication can be used with the BeeVision dimensioning device. However, for accurate volume measurement and optimal performance, we recommend using scales specified by BeeVision. For further details, please contact our Technical Support Team.

Yes, the BeeVision dimensioning device is compatible with barcode scanners that support USB port connections, enhancing the flexibility of your warehouse automation processes.

Yes, you can access past dimensioning results through the WebUI on the BeeVision dimensioning device. Additionally, all volume measurement data can be retrieved via WebService. For detailed instructions to support warehouse automation, please refer to our documentation.

No, the BeeVision dimensioning device retains unsent volume measurement data in its memory and periodically attempts to send it to the remote server. This process continues until a successful response is received, ensuring accurate dimensioning and data security.
